KIOTI DK Series ROPS Overview

This new generation Kioti compact CK Series has the option of a 30, 37 & 42hp Daedong diesel engine and comes with a hydrostatic transmission and HST pedals.

CK3710 ROPS Compact Tractor
ENGINE BRAKES
Daedong 3B183LWM-E Independent Oil Immersed Disc Brakes
Liquid Cooled 3 Cylinder Diesel Cast Iron Transmission and Axle Housing
1829cc Displacement
37hp @ 2800 RPM (max) OPERATOR ENVIRONMENT
34 Litre Fuel Tank Capacity Front Work Lights with Indicators/Brake Lights
Step Through Platform
 TRANSMISSION Under Bonnet Muffler
3 Range Hydrostatic Drive Comfort Seat
Cruise Control HST models Tool Box
4 Wheel Drive
Rear Differential Lock TRAVEL SPEED
Infinite Speeds From 0-25 km/h F/R
HYDRAULICS & LINKAGE
Manual Linkage Control DIMENSIONS
44.4 l/min Total Flow Overall Length  3070 mm
Category 1 Three Point Linkage Overall Width   1400 mm
Draw Bar Overall Height  2650 mm
 4 Hydraulic Remotes (2 Rear, 2 Front w/Joystick) Wheelbase        1670 mm
740kg Max Rear Lift Capacity 610mm Behind Lift
TYRES
POWER TAKE OFF Industrial Front  25/8 5×14
540 Rpm Rear PTO Speed                  Rear   15/19.5
 *NOTE: The specifications are subject to change for the purpose of improvement without any notice



CK4210 ROPS Compact Tractor
ENGINE BRAKES
Daedong 3B183LWM-E Independent Oil Immersed Disc Brakes
Liquid Cooled 3 Cylinder Diesel Cast Iron Transmission and Axle Housing
1826cc Displacement
42hp @ 2800 RPM (max) OPERATOR ENVIRONMENT
34 Litre Fuel Tank Capacity Front Work Lights with Indicators/Brake Lights
Step Through Platform
TRANSMISSION Under Bonnet Muffler
9×3 Synchro Shuttle or 3 Range Hydrostatic Drive Comfort Seat
Cruise Control HST Models Tool Box
4 Wheel Drive
Rear Differential Lock TRAVEL SPEEDS
Speed Range 1.52-23.56 km/h (Manual)
HYDRAULICS & LINKAGE Infinite Speeds from 0-25 km/h F/R (HST)
Manual Linkage Control
44.4 l/min Total Flow DIMENSIONS
Category 1 Three Point Linkage Overall Length  3070 mm
Draw Bar Overall Width   1400 mm
4 Hydraulic Remotes (2 Rear, 2 Front w/Joystick) Overall Height  2650 mm
740kg Max Rear Lift Capacity 610mm Behind Lift Wheelbase        1670 mm
Ground Clearance    340 mm
TYRES
Industrial  Front  25/8 5×14 WEIGHT
 Rear 15/19.5 Manual 1195kg
HST 1200kg
  *NOTE: The specifications are subject to change for the purpose of improvement without any notice



CK4220 Cabin Compact Tractor
ENGINE BRAKES
Daedong 3B183LWM-E Independent Oil Immersed Disc Brakes
Liquid Cooled 3 Cylinder Diesel Cast Iron Transmission and Axle Housing
1826cc Displacement
42hp @ 2800 RPM (max) OPERATOR ENVIRONMENT
34 Litre Fuel Tank Capacity Front Work Lights with Indicators/Brake Lights
Step Through Platform
TRANSMISSION Under Bonnet Muffler
12×12 Synchro Shuttle or 3 Range Hydrostatic Drive Comfort Seat
Cruise Control HST Models Deluxe A/C Cabin
4 Wheel Drive
Rear Differential Lock TRAVEL SPEEDS
Speed Range 1.52-23.56 km/h (Manual)
HYDRAULICS & LINKAGE Infinite Speeds from 0-25 km/h F/R (HST)
Manual Linkage Control
44.4 l/min Total Flow DIMENSIONS
Category 1 Three Point Linkage Overall Length  3070 mm
Draw Bar Overall Width   1400 mm
4 Hydraulic Remotes (2 Rear, 2 Front w/Joystick) Overall Height  2650 mm
740kg Max Rear Lift Capacity 600mm Behind Lift Wheelbase        1670 mm
Ground Clearance    340 mm
TYRES
Industrial  Front  25/8 5×14
 Rear 15/19.5
  *NOTE: The specifications are subject to change for the purpose of improvement without any notice
